Naked
500F
Naked inline-four street muscle
The 500F takes the 470 cc inline-four into a stripped-back roadster tuned for the street. It makes 54 kW, sits on a steel trellis frame, and keeps things approachable with a low 795 mm seat.
- 470 cc inline-four, 54 kW
- Low 795 mm seat, 175 kg curb weight
- Steel trellis diamond frame
Specifications
500F specs
Engine
- Engine type
- 4 inline-cylinder, DOHC, 16-valve, liquid-cooled
- Displacement
- 470 cc
- Bore x Stroke
- 59 x 43 mm
- Maximum power
- 54 kW @ 11000 rpm
- Maximum torque
- 48 N·m @ 9500 rpm
- Fuel delivery
- BOSCH EFI
Chassis
- Frame
- Integrated steel trellis diamond frame
- Rear swing arm
- Swing arm (aluminium alloy)
- Front suspension
- Inverted fork, adjustable damping
- Front brake
- 300 mm dual floating disc, floating caliper
- Rear brake
- 220 mm single disc, 1-piston floating caliper (TAISKO)
- Front tyre
- CST S1, 120/70 ZR17
- Rear tyre
- CST S1, 180/55 ZR17
Dimensions
- Length x Width x Height
- 2015 x 805 x 1090 mm
- Wheelbase
- 1395 mm
- Seat height
- 795 mm
- Curb weight
- 175 kg (dry 165 kg)
- Fuel capacity
- 15.5 L
- Steering angle
- 33.5°
- Rake angle
- 24.5°
Specifications are provided by ZX Moto and may change. Confirm exact details with our team before purchase.
