Sport
500RR
Track-bred inline-four supersport
The 500RR pairs a high-revving 470 cc inline-four with a single-sided swingarm and TAISKO brakes. It makes 62 kW (84 hp) at 13,500 rpm, and ZX Moto quotes a top speed of 235 km/h, suiting both road and track.
- 470 cc inline-four, 62 kW / 84 hp
- 235 km/h quoted top speed
- Single-sided swingarm, TAISKO brakes
Specifications
500RR specs
Engine
- Engine type
- 4 inline-cylinder, DOHC, 16-valve, liquid-cooled
- Displacement
- 470 cc
- Bore x Stroke
- 59 x 43 mm
- Maximum power
- 62 kW (84 hp) @ 13500 rpm
- Maximum torque
- 46 N·m @ 11500 rpm
- Compression ratio
- 12.9:1
- Clutch
- Wet multi-plate slipper clutch
- Fuel delivery
- BOSCH EFI
- Top speed
- 235 km/h
Chassis
- Frame
- Integrated steel trellis diamond frame
- Rear swing arm
- Single-sided swing arm (aluminium alloy)
- Front suspension
- Inverted 41 mm fork, fully adjustable preload and damping
- Front brake
- 300 mm dual floating disc, 4-piston opposed caliper (TAISKO)
- Rear brake
- 220 mm single disc, 2-piston opposed caliper (TAISKO)
- Front tyre
- CST S5, 120/70 ZR17
- Rear tyre
- CST S5, 180/55 ZR17
Dimensions
- Length x Width x Height
- 2005 x 705 x 1125 mm
- Wheelbase
- 1395 mm
- Seat height
- 800 mm
- Curb weight
- 168 kg (net 158 kg)
- Fuel capacity
- 15 L
Specifications are provided by ZX Moto and may change. Confirm exact details with our team before purchase.
