Off-road
MX250
Purpose-built for the dirt
The MX250 is a competition-focused off-road single: 249.9 cc, DOHC, revving to 14,000 rpm, with fully adjustable KYB suspension front and rear, 325 mm of ground clearance and a tall 960 mm seat. Built to be ridden hard on dirt.
- 249.9 cc DOHC single, revs to 14000 rpm
- KYB fully adjustable suspension
- 325 mm ground clearance, 105 kg
Specifications
MX250 specs
ZX Moto does not publish a peak power figure for the MX250.
Engine
- Engine type
- Single-cylinder, DOHC, 4-valve, 4-stroke
- Displacement
- 249.9 cc
- Bore x Stroke
- 79 x 51 mm
- Compression ratio
- 13.9:1
- Clutch
- Wet multi-plate slipper, hydraulic
- Transmission
- 5-speed
- Throttle
- Cable-operated
- Fuel supply
- BOSCH EFI (dual fuel injector)
Chassis
- Frame
- Twin-spar frame
- Front suspension
- KYB inverted fork, fully adjustable damping
- Rear suspension
- KYB shock with external reservoir, fully adjustable damping
- Suspension travel
- 305 / 302 mm
Dimensions
- Length x Width x Height
- 2168 x 805 x 1265 mm
- Wheelbase
- 1485 mm
- Ground clearance
- 325 mm
- Seat height
- 960 mm
- Net weight
- 105 kg
- Fuel capacity
- 6.5 L
- Steering angle
- 42°
- Rake angle
- 28°
Specifications are provided by ZX Moto and may change. Confirm exact details with our team before purchase.
